Frequency response:
S/N ratio:
Separation:
Rear channels tone controls:
Inputs:
Outputs:
Components:
Dimensions:
Weight: |
|
|
20 Hz - 20 kHz (±3 dB, SQ, Matrix, 2->4 modes)
10 Hz - 100 kHz (2-channel, discrete modes)
80 dB (SQ, Matrix, 2>4 modes)
90 dB (2-channel, discrete modes)
20 dB (stereo front)
14 dB (stereo rear)
20 dB (front/rear)
20 dB (front/rear diagonal)
±10 dB (100 Hz)
±10 dB (10 kHz)
250 mV/100 kΩ (SQ, R-MTX, 2>4, Discrete)
750 mV/100 kΩ (2/4 channel, Din)
Front (500 mV/5 kΩ)
Rear (500 mV - 2 V/ 5kΩ)
250 mV/5 kΩ (2/4 channel),
30 mV/5 kΩ (Din)
69 transistors
84 diodes
40 x 14,9 x 32,7 cm
5,9 kg. |
|
